Characteristics:
1. LCD display for temperatur
2. 8-bit micro process control system
3. Various temperature,cold laminating function for different laminating needs.
4. New type temperature regulation switch,accurate temperature,longer lifespan
Model: | PDL-230 | PDL-330 |
Laminating Width: | 240mm | 330mm |
Laminating Speed: | 0.52m/min | 0.52m/min |
Mounting Distance between rollers: | 2mm | 2mm |
Operation Temperature: | 0-180 ℃ | 0-180 ℃ |
Heating System: | infrared heating lamp | infrared heating lamp |
Warm Up Time: | 3mins | 3mins |
Laminating Thickness: | up to 250mic | up to 250mic |
Roller Diameter: | 25mm | 25mm |
Roller: | 4 | 4 |
Document Reverse Function: | Yes | Yes |
Cooling Fan: | N/A | N/A |
Power Consumption: | 420W | 620W |
Power Supplies(optional): | 110V/60HZ, 220V/50HZ | 110V/60HZ, 220V/50HZ |
Machine Dimension: | 410x240x105mm | 500x240x105mm |
