PDL-330

Availability:
Quantity:

PDL-330-1

Characteristics:

1. LCD display for temperatur
2. 8-bit micro process control system
3. Various temperature,cold laminating function for different laminating needs.
4. New type temperature regulation switch,accurate temperature,longer lifespan



Model:

PDL-230

PDL-330

Laminating Width:

240mm

330mm

Laminating Speed:

0.52m/min

0.52m/min

Mounting Distance   between rollers:

2mm

2mm

Operation Temperature:

0-180

0-180

Heating System:

infrared heating lamp

infrared heating lamp

Warm Up Time:

3mins

3mins

Laminating Thickness:

up to 250mic

up to 250mic

Roller Diameter:

25mm

25mm

Roller:

4

4

Document Reverse   Function:

Yes

Yes

Cooling Fan:

N/A

N/A

Power Consumption:

420W

620W

Power   Supplies(optional):

110V/60HZ, 220V/50HZ

110V/60HZ, 220V/50HZ

Machine Dimension:

410x240x105mm

500x240x105mm
