PD330-1

Quantity:
  • PD330-1

Characteristics:

Various temperature, cold laminating function for different laminating needs.

High quality, low noise, stable motor.

Recoverable over-heat protection system, safer to machine and user

PD330-1

   Model PD240-1 PD330-1
Laminating Width 240mm 330mm
Mounting Distance Between Rollers 2mm 2mm
Laminating Speed 0.5m/min 0.5m/min
Operation Temperature 80°-160° 80°-160°
Roller 4 4
Roller Diamter 25mm 25mm
Heating System(optional) Infrared heating lamp/mica sheet heater Infrared heating lamp/mica sheet heater
Warm Up Time 3min 3min
Machine Voltage 110V/220V 110V/220V
Power Consumption 420W 620W
Document Reverse Function Yes Yes
Laminating Thickness 80mic-250mic 80mic-250mic
Machine Dimension 402x230x101mm 492x230x101mm
Machine Net Weight

6.5KG      7.8KG
Package

2pcs/CTN 2pcs/CTN
